Semi-Automatic Handheld Screwing Machine With Air Blow Screw Feeder

The handheld screw tightening machine with portable air blow automatic screw feeder is an efficient, economical automatic screwing tool. It realizes automatic air blow screw feeding, sorting and fastening with one-handed operation, which doubles work efficiency - one worker's output equals three manual operators. It effectively boosts production capacity and reduces labor costs remarkably.

◆ With more than a decade of immersion in the screw tightening machine industry, it ensures the stability and durability of the screw fastening machine.



◆ We provide factory-direct sales accompanied by guaranteed after-sales service.



◆ Featuring mass production, we ensure fast delivery and offer more competitive prices compared to counterparts in the industry.



◆ Our customized services are capable of promptly presenting solutions in accordance with customers' products and requirements.

Double-click the electric screwdriver trigger with your index finger within one second, and the screw will be delivered to the screwdriver bit automatically. Hold the workpiece with one hand, and align the screw to the screw hole with the other hand. Press and hold the trigger (keep your index finger pressed) to fasten the screw. Then lift the screwdriver up about 20 mm to maintain a safe distance (the bit shall be 20 mm away from the workpiece), and release the trigger with your index finger to activate automatic feeding for the next screw. Repeat the above steps. Proficiency in operation will further improve the working efficiency.

• This semi-automatic handheld screwing machine with air blow screw feeder enables automatic screw feeding, sorting and fastening with one-handed operation.
• Torsion precision and convenient adjustment, ensure the quality of screw fastening.
• Low volume and noise, convenient maintenance. Light weight and small, mobility and save space.
• Warning function when lack of screws. (Acousto-optic alarm)
• High efficiency. No need to pick up screws, move screws and put screws. Just need to aimed at the screw hole to fasten the screws.
• Screw feeding very fast, feeding speed 0.6-0.8S per screw, the efficiency depends on how fast your operator can work.

This handheld screwing machine is equipped with an air-blow screw feeding mechanism. This mechanism offers excellent versatility and is compatible with various screw types, including Phillips screws, Torx screws, hexagon socket screws and slotted screws.

After-sales service is not merely the end; rather, it is the starting point of our everlasting companionship. We are available online 24 hours a day, standing by at all times, much like a guardian star, escorting you throughout your entire usage journey.

All the machines are provided with safe packing in plywood cases. The solid packing ensures that the machines will not be damaged during transit.
